Chains, PyFunc Models and Unity Catalog Registration

What it is

A chain links a prompt, a retriever and an LLM so one call turns a question into an answer. To deploy it, you package the chain as an MLflow model, log it with everything it needs, and register it in Unity Catalog so it can be versioned, governed and served.

The pyfunc flavor is the general wrapper: a Python class whose predict method can clean the input before the chain runs and reshape the output after it.

How it works

A simple chain

A minimal chain in LangChain style is a prompt template piped into a chat model and an output parser. ChatDatabricks from the databricks_langchain package calls a Databricks serving endpoint.

from databricks_langchain import ChatDatabricks
from langchain_core.prompts import ChatPromptTemplate
from langchain_core.output_parsers import StrOutputParser

prompt = ChatPromptTemplate.from_template("Use this context: {context}\nQuestion: {question}")
llm = ChatDatabricks(endpoint="databricks-meta-llama-3-3-70b-instruct")
chain = prompt | llm | StrOutputParser()

Read requirements literally. If the scenario asks for a plain string answer, the chain ends in a string output parser; if it must ground answers in documents, a retriever fills {context} before the prompt.

Wrapping the chain in pyfunc

Subclass mlflow.pyfunc.PythonModel. load_context runs once when the model loads, so build clients and the chain there; predict(self, context, model_input, params=None) runs per request.

class RagChain(mlflow.pyfunc.PythonModel):
    def load_context(self, context):
        self.chain = build_chain()                   # retriever + prompt + LLM
    def predict(self, context, model_input, params=None):
        question = model_input["question"][0].strip()  # pre processing
        answer = self.chain.invoke({"question": question})
        return [answer.strip()]                      # post processing

Pre processing is where you validate, mask or rewrite input; post processing is where you strip text, add citations or enforce a format. Neither belongs in the prompt when plain code can do it reliably.

The elements a RAG model needs

Databricks recommends models from code for agents: the class lives in a Python file that calls mlflow.models.set_model(...), and you pass the file path as python_model. For agents, ResponsesAgent is the current interface; MLflow infers its signature automatically, while a plain pyfunc needs a signature or an input example.

Logging and registering to Unity Catalog

Point the registry at Unity Catalog, then log with a three level name. In MLflow 3, name replaces the deprecated artifact_path.

mlflow.set_registry_uri("databricks-uc")
with mlflow.start_run():
    info = mlflow.pyfunc.log_model(
        name="rag_chain", python_model=RagChain(),
        input_example={"question": ["What is Delta Lake?"]},
        resources=[DatabricksVectorSearchIndex(index_name="main.docs.chunks_index")],
        registered_model_name="main.docs.rag_chain")

You can also log first and call mlflow.register_model(info.model_uri, "main.docs.rag_chain"). Each registration creates a new model version; aliases such as champion point serving and jobs at the version you approve.

How the exam asks about this

• "Registration to Unity Catalog fails with a missing signature error." Add an input example or an explicit signature when logging.
• "User input must have extra whitespace removed and answers trimmed to the first paragraph." Use a pyfunc model with pre and post processing in predict.
• "The model is served but cannot reach the Vector Search index." Declare the index in resources when logging so automatic authentication covers it.
